Name: Precision Casting Cabinet parts
Type: force structure
Model: 40Cr steel
Brand: Yong Sheng Precision Casting
Customization: can be formulated with customer demand
Item Number: YSMP
Description: Auto Parts Tools casting
Casting process: investment casting
Material: carbon steel casting, carbon steel casting
Product Description
Casting Process: Water glass investment casting process
Material Standards:... GB.ASTM AISI DIN BS JIS.
Maximum Size: 1000mm
Weight range: 0.10-100Kg
Casting Dimension Tolerance: CT7 level
Annual production: 8,000 tons
Casting pores prevention
1, for complex thin-walled castings, to improve the precision casting shell permeability, where possible, can be set at the highest point of the vent. A reasonable set of gating system, prevent pouring volume of gas, and is conducive to the cavity gas emissions.
2, an appropriate increase in pouring temperature, to minimize ladle pouring cup from the mouth to reduce the casting speed, so that a smooth liquid metal filling, to prevent the involvement of gas, so that the cavity in the gas and the liquid metal can be smoothly discharged.
3, dewaxing mold material should be excluded clean, residual mold material should be minimized.
4, firing shell to the full, should be high enough temperature; sol and ethyl silicate shell 950 to 1100 degrees Celsius, the water glass shell 850 to 900 degrees Celsius; holding time is greater than & ,, to ensure precision casting shell through roasting, gas evolution substance fully excluded. Roasting complete shell is white or pale gray, there should be no dark spots |
|
